Bennett

Posted: 3 November 2023

Bennett Marine stands as the global leader in trim tab innovation, quality, and service within the marine industry. They specialize in offering a range of cutting-edge products, including trim tabs and hatch lifter systems, aimed at enhancing the performance of your watercraft. Bennett's trim tabs are designed to adjust your vessel's running angle, offering a multitude of advantages such as reducing bow rise, facilitating quicker planing, correcting listing, improving visibility, and boosting overall efficiency.

For a comprehensive view of Bennett Marine's product offerings and full price list please select Pricebook Page 63. Here, you'll find full listings of Bennett's extensive lineup. Additionally, for in-depth insights into each product's features and capabilities, please refer to the accompanying brochure. Bennett Marine remains dedicated to providing top-notch solutions for the marine industry, ensuring that your boating experience is both efficient and enjoyable.Additionally please see the following broschure for detailed product description.

BENNETT HYDRAULIC TRIM TAB SETS WITH EURO-STYLE CONTROL 9" CHORD

DESCRIPTION	PB-REF
12" X 9" 8Trim Tab Set with Euro Rocker Control	129E
18" X 9" Tm 12V Euro Rocker Control	189E
24" X 9" Tm 12V Euro Rocker Control	249E
30" X 9" Tm 12V Euro Rocker Control	309E
36" X 9" Tm 12V Euro Rocker Control	369E
42" X 9" Tm 12V Euro Rocker Control	429E
48" X 9" Tm 12V Euro Rocker Control	489E
54" X 9" Tm 12 V Euro Rocker Control	549E
Eurostyle control provides a weatherproof rocker switch for harsh environments. Other Options available.

"24" X 9" Tm 12V Euro Rocker Control"

BENNETT HYDRAULIC TRIM TAB SETS WITH EURO-STYLE CONTROL 12" CHORD

DESCRIPTION	PB-REF
12 X 12 TM 12V EURO ROCKER CONTROL	1212E
18 X 12 TM 12V EURO ROCKER CONTROL	1812E
24 X 12 TM 12V EURO ROCKER CONTROL	2412E
30 X 12 TM 12V EURO ROCKER CONTROL	3012E
36 X12 TM 12V EURO ROCKER CONTROL	3612E
42 X 12 TM 24V EURO ROCKER CONTROL	4212E
48 X 12 TM 24V EURO ROCKER CONTROL	4812E
54 X 12 TM 12V EURO ROCKER CONTROL	5412E
EUROSTYLE ROCKER CONTROL STND PACKED (CLAM SHELL)	ES2000
Eurostyle control provides a weatherproof rocker switch for harsh environments. Other Options available.

"18 X 12 TM 12V EURO ROCKER CONTROL"

HYDRAULIC TRIM TAB SETS WITH ELECTRONIC INDICATOR CONTROL

DESCRIPTION	PB-REF
12 X 12 TM 12V EIC CONTROL	1212EIC
12 X 9 TM 12V EIC CONTROL	129EIC
18 X 9 TM 12V EIC CONTROL	189EIC
18 X 12 TM 12V EIC CONTROL	1812EIC
24 X 9 TM 12V EIC CONTROL	249EIC
24 X 12 TM 12V EIC CONTROL	2412EIC
30 X 9 TM 12V EIC CONTROL	309EIC
30 X 12 TM 12V EIC CONTROL	3012EIC
Supplied with Electronic Indicator Control(EIC) integrated display.

"12 X 12 TM 12V EIC CONTROL"

HYDRAULIC TRIM TAB SETS WITH AUTO TRIM PRO

DESCRIPTION	PB-REF
HYDRAULIC 12 x 9 w/ ATP	129ATP
HYDRAULIC 12 x 12 w/ ATP	1212ATP
HYDRAULIC 18 X 9 W/ ATP	189ATP
HYDRAULIC 18 X 12 W/ ATP	1812ATP
HYDRAULIC 24 X 9 W/ ATP	249ATP
HYDRAULIC 24X12 W/ ATP	2412ATP
AutoTrim Pro Sensor Kit	ATPSENSTD
Autotrim Pro For Classic Hydraulic Systems (12V)	AP000A1HA
Autotrim Pro For Bolt Electric Systems (12V)	AP000A1BC
Atp Y Harness	ATPBRCABLE
Bridge Display, Auto Tab Pro, Gen 4	ATPDISPLAYG4-1
Atp Hydraulic Control Box	ATPHYDCTRL
AutoTrim Pro automatically levels the pitch and roll of your boat, adjusting your trim tabs to changes in vessel speed, sea conditions and shifting weight. Enjoy the convenience of riding in auto mode, or shift to full manual mode anytime.

"AutoTrim Pro Sensor Kit"

HYDRAULIC TRIM TAB SETS WITH INTEGRATED HELM CONTROL (OBI)

DESCRIPTION	PB-REF
Hydraulic Trim Tab Sets w/ Integrated Helm Control (OBI) 12 X 9 TM 12V OBI CTRL	129OBI
Hydraulic Trim Tab Sets w/ Integrated Helm Control (OBI) 18 X 9 TM 12V OBI CTRL	189OBI
Hydraulic Trim Tab Sets w/ Integrated Helm Control (OBI) 24 X 9 TM 12V OBI CTRL	249OBI
Hydraulic Trim Tab Sets w/ Integrated Helm Control (OBI) 30 X 9 TM 12V OBI CTRL	309OBI
Hydraulic Trim Tab Sets w/ Integrated Helm Control (OBI) 12 X 12 TM 12V OBI CTRL	1212OBI
Hydraulic Trim Tab Sets w/ Integrated Helm Control (OBI) 18 X 12 TM 12V OBI CONTROL	1812OBI
Hydraulic Trim Tab Sets w/ Integrated Helm Control (OBI) 24 X 12 TM 12V OBI CONTROL	2412OBI
Hydraulic Trim Tab Sets w/ Integrated Helm Control (OBI) 30 X 12 TM 12V OBI CONTROL	3012OBI
Bennett Electric Trim Tab Controls Integrated Helm Control (Electric)	OBI9000E
Bennett Electric Trim Tab Controls Integrated Helm Control (Electric) Dual station	OBI9000E-DS

"Hydraulic Trim Tab Sets w/ Integrated Helm Control (OBI) 18 X 9 TM 12V OBI CTRL"

BENNETT SPORT TRIM TAB SETS

DESCRIPTION	PB-REF	PRICE
SPORT TAB 8 X 10	M80	£572
SPORT TAB 10 X 12	M120	£610
SPORT TABS 12 X 9 BENNETT STANDARD ELP	ST9	£689
SPORT TABS 12 X 12 BENNETT STANDARD ELP	ST12	£877
SPORT TABS 12 X 16 BENNETT STANDARD ELP	ST16	£956

"SPORT TAB 8 X 10"

SPORT TABS WITH PRE-INSTALLED INDICATORS

DESCRIPTION	PB-REF
M80 WITH EIC5000	M80EIC
M120 WITH EIC5000	M120EIC
SPORT TABS 12 X 9 W/EIC BENNETT STND ELP	ST9EIC
SPORT TABS 12 X 12 W/EIC BENNETT STND ELP	ST12EIC
SPORT TABS 12 X 16 W/EIC BENNETT STND ELP	ST16EIC
M80 with ATP	M80ATP
M120 with ATP	M120ATP

"M120 with ATP"

BENNETT BOLT ELECTRIC TRIM TAB SETS

DESCRIPTION	PB-REF
Bolt Less Tabs	BOLTBLT
12 X 4 Trim Tab System	BOLT124
Bolt 12 X 9 Trim Tab System	BOLT129
18 X 9 Trim Tab System	BOLT189
24 X 9 Trim Tab System	BOLT249
Bolt 12 X 12 Trim Tab System	BOLT1212
Bolt 18 X 12 Trim Tab System	BOLT1812
24 X 12 Trim Tab System	BOLT2412
6 X 12 Edge Mount	BOLT612ED
Bolt 9 X 12 Edge Mount	BOLT912ED
Bolt 12 X 12 Edge Mount	BOLT1212ED
12 X 16 Bolt Trim Tab System	BOLT1216HD

"6 X 12 Edge Mount"

BENNETT BOLT ELECTRIC TRIM TAB COMPONENTS

DESCRIPTION	PB-REF
Conversion Kit Lenco To Bolt Packed	BOLTLKCON
Hydraulic To Bolt Conversion Kit	HYDBOLTCON
Bolt Rocker Switch Control	BRC4000
Bolt Relay Module W/Indication Packed	BCI8500
Bolt Keypad W/Indication Packed	BCI8700
Bolt Soft Touch Helm Control W/Indication Packed	BCI8000
25 Ft Bolt Act Wire Ext	BAW2025
30 Ft Bolt Act Wire Ext	BAW2030
35 Ft Bolt Act Wire Ext	BAW2035
40 Ft Bolt Act Wire Ext	BAW2040
25 Ft Bolt Helm Keypad Wire Ext	BHW4025
30 Ft Bolt Helm Keypad Wire Ext	BHW4030
35 Ft Bolt Helm Keypad Wire Ext	BHW4035
40Ft Bolt Helm Keypad Wire Ext	BHW4040
Jun Box, Two Disp, Two Rms	JUNBOX2D2A
5 Ft Bolt Act Wire Ext	BAW2005
15 Ft Bolt Act Wire Ext	BAW2015
20 Ft Bolt Act Wire Ext	BAW2020
5 Ft Bolt Helm Keypad Wire Ext	BHW4005
7 Ft Bolt Helm Keypad Wire Ext	BHW4007
10 Ft Bolt Helm Keypad Wire Ext	BHW4010
Bolt Electric Actuator	BEA2000
Bolt Adjustable Actuator 12V	BEA3000
Durable and depenable trim tab system designed for fast and simple installlation.

"Hydraulic To Bolt Conversion Kit"

HYDRAULIC TRIM TAB SETS WITHOUT CONTROLS 9-INCH CHORD

DESCRIPTION	PB-REF
12 X 9 TM 12V LESS CONTROL	129
18 X 9 TM 12V LESS CONTROL	189
24 X 9 TM 12 V LESS CONTROL	249
30 X 9 TM 12 V LESS CONTROL	309
36 X 9 TM 12 V LESS CONTROL	369
42 X 9 TM 12 V LESS CONTROL	429
48 X 9 TM 12 V LESS CONTROL	489

"24 X 9 TM 12 V LESS CONTROL"

HYDRAULIC TRIM TAB SETS WITHOUT CONTROLS 12-INCH CHORD

DESCRIPTION	PB-REF
12 X 12 TM 12V LESS CONTROL	1212
18 X 12 TM 12V LESS CONTROL	1812
24 X 12 TM 12V LESS CONTROL	2412
30 X 12 TM 12V LESS CONTROL	3012
36 X12 TM 12V LESS CONTROL	3612
42 X 12 TM 12V LESS CONTROL	4212
48 X 12 TM 12V LESS CONTROL	4812
54 X 9 TM 12 V LESS CONTROL	549
54 X 12 TM 12V LESS CONTROL	5412

"12 X 12 TM 12V LESS CONTROL"

STANDARD TRIM PLANE ASSEMBLIES - 9" CHORD

DESCRIPTION	PB-REF
12 x 9 Standard (10 x 9 available)	TPA129
18 x 9 Standard (14 & 16 x 9 available)	TPA189
24 x 9 Standard (20 & 22 x 9 available)	TPA249
30 X 9 Standard	TPA309
36 X 9 Standard	TPA369
42 X 9 Standard	TPA429

"18 x 9 Standard (14 & 16 x 9 available)"

STANDARD TRIM PLANE ASSEMBLIES - 12" CHORD

DESCRIPTION	PB-REF
12 X 12 Standard	TPA1212
18 X 12 Standard (14 & 16 X 12 Available)	TPA1812
24 X 12 Standard (20 & 22 X 12 Available)	TPA2412
24 X 12 Tpa Pnch F/Dual Act	TPA2412DA
30 X 12 Standard	TPA3012
30X12 W/1"Uf Tm Dual Act Tpa	TPA3012UFD
Tpa 36 X 12 Tm Da 14Ga 2B No Fins	TPA3612DA
36 X 12 W/1" Uf Tm Tpa	TPA3612UF
42 X 12 Standard	TPA4212
48 X 12 Standard	TPA4812
54 X 12 Standard	TPA5412
Price shown is for a single Trim Plane (Tab)

"24 X 12 Standard (20 & 22 X 12 Available)"

SPORT TAB TRIM PLANE ASSEMBLIES

DESCRIPTION	PB-REF
TPA 10X12 TM SA 1.2"DF 2B (M120) 7/32" MTG HOLES	TPAM120
TPA 8 X 10 FOR M80 SPORT TAB	TPAM80
12 X 12 TPA FOR SPORT TAB ELP	TPAST12
Trim Plane Assembly for Sport Tabs 12 X 16 PORT TPA FOR ST16 ELP	TPAST16P
Trim Plane Assembly for Sport Tabs 12 X 16 STBD TPA FOR ST16 ELP	TPAST16S
Price shown is for a single Trim Plane (Tab)

"Trim Plane Assembly for Sport Tabs 12 X 16 PORT TPA FOR ST16 ELP"

ANODES

DESCRIPTION	PB-REF
Anode Zinc R3 W/Fast.	ZINC3
Anode Zinc R4 W/Fast.	ZINC4

BENNETT TRIM RAM ACTUATOR REPLACEMENT PARTS

DESCRIPTION	PB-REF
Upper Hinge With "O"-Ring Bag & Tag	A1103
Lower Hinge	A1113
Rivet Clear Lower Hinge	A1113RC
Rc Lower Hinge And Ss Pin 1.23" Lg	A1114
Kit Lower Hinge Rivet Clear With Pin	A1114RC
Pin Ss 1.23" Lg For Lower Hinge	A1115
Actuator Uh O-Ring(-224)	A1120
Act Piston O-Ring(-220)	A1121
Act Assy Stnd 2.0 Sp 2.5 Stroke (No Coil)	A1101A
Act Assy Stnd 2" Spacer 2.5 Strk Retn. Div. (No Coil)	A1101ARD
Act Assy Stnd 2.0 Sp 2.5 Strk 30Ft No Conne	A1101CP
Act Stand W/Coil Deutsch 10Ft(Packed)	A1101CP10T
Actuator Assy Stnd 2.0 Sp 2.5 Strk 10Ft Eic	A1101CPEIC
Actuator Assy Stnd 2.0 Sp 2.5 Strk 20Ft Eic	A1101CPEIC20
Act Stnd Eic Conn 10Ft Reten Dev	A1101CPEICRD
Actuator Assy Standard 2.5 Stroke Eic 15Ft Reten Dev.	A1101CPEICRD15
Actuator Assy Small 2.0 Sp 2.5" Stroke No Coil	A1200S
Actuator Assy Small 2.0 Sp 2.5 Strk 30 Ft (No Conn)	A1200SCP
Uh W/Snsr 30' W-Clip-Instr	CC3003P

"Upper Hinge With "O"-Ring Bag & Tag"

SELF-LEVELING TAB SYSTEMS

DESCRIPTION	PB-REF
KIT SLT 6X8 COMPLETE	SLT6
KIT SLT 10X10 COMPLETE	SLT10

BENNETT CONVERSION KITS FOR INSTA, LENCO AND TRIM MASTER

DESCRIPTION	PB-REF
Insta-Trim Conversion Kit	V351CK
Lenco Conversion Kit	V351LK
Trim Master Conversion Kit	V351TMCK

"Insta-Trim Conversion Kit"

BENNETT REPLACEMENT PARTS: HARDWARE KITS

DESCRIPTION	PB-REF
Hardware Kit W/3" Pipe Nipple. Clam Shell	H1170A
Hardware Kit W/4" Pipe Nipple	H1170A4
Hardware Kit #2 For Dual Act 3" Nippels	H1170B
Hardware Kit #2 For Da W/4" Pipe Nipple	H1170B4

"Hardware Kit W/3" Pipe Nipple. Clam Shell"

ELECTRICAL REPLACEMENT PARTS: RELAY MODULES

DESCRIPTION	PB-REF
RELAY MODULE 12 VOLT	RM12
RELAY MODULE 24 VOLT	RM24

"RELAY MODULE 12 VOLT"

BENNETT WIRING HARNESSES

DESCRIPTION	PB-REF
Wire Harness One Mate/Lock Plug 22 Ft	WH100022
Wire Harness One Mate/Lock Plug 25 Ft	WH100025
Wire Harness One Mate/Lock Plug 30 Ft	WH100030

BENNETT HYDRAULIC POWER UNITS

DESCRIPTION	PB-REF
12V Hydraulic Power Unit	V351HPU1
12V Hpu W/Deutsch Connector	V351HPU1D
24V Hydraulic Power Unit	V351HPU2
24V Hpu W/Deutsch Conn.	V351HPU2D

"12V Hydraulic Power Unit"

BENNETT HYDRAULIC POWER UNIT RELATED COMPONENTS

DESCRIPTION	PB-REF
Hydraulic Power Unit 24V. Mate/Lock (High Psi)	V351HPU2SP
One Valve Hpu 12V	V351V
Filler Plug	VP1140
Hex Retainer	VP1141
Hpu Faceplate	VP1144
Fitting Brass 1/8 Pipe To 1/4 Tube Conn W/ Nut	VP1146
Mounting Bracket For Hpu	H1179
O-Ring -015 For Hpu	VP1155
O-Ring -008 For Hpu	VP1157
Quad Ring For Hpu	VP1158
Valve Seat W/ Orings	VP1159
Hpu Mounting Angle	H1186
12V Solenoid Valve Green Wire (Bag)	VP1135G
24V Solenoid Valve Green Wire (Bag)	VP1135G24V
12V Solenoid Valve Red Wire (Bag)	VP1135R
Catalog # 24V Solenoid Valve Red Wire (Bag)	VP1135R24V
Lexan Cover	VP1138
Hpu Fluid Reservoir Standard	VP1139

"Lexan Cover"

BENNETT REPLACEMENT PARTS: HARDWARE

DESCRIPTION	PB-REF
2" Brass Pipe Nipple	H11712
3" Brass Pipe Nipple	H11713
4" Brass Pipe Nipple	H11714
5" Brass Pipe Nipple	H11715
6" Brass Pipe Nipple	H11716
Female Elbow 1/4 X 1/8 Npt ( Brass)	H1172
Tube Bending Clip	H1173
Screw #14 X 1-1/2 Sms 316Ss, Typ A, Phil Pan Bag& Tag	H1174
Screw Pan Head Phil 1/4-20 X 3/4"Lg 316Ss	H1175
Screw Mach 1/4-20X1-1/4 Pan Hd Phl 18-8Ss	H1181
Retention Device, For (2) Actuatos	PRIRD1
Hardware Kit For Prince Retention Device	PRIRDHDW
Hydraulic Tubing 20 Ft	T112520
Hydraulic Tubing 30 Ft	T112530
Hydraulic Tubing M80/M120 Pre-Con 8Ft	T1125M
"T" Fitting 1/4 Compression Brass W/Nuts	T1126
Nut W/Ferrule (Bag)	T1127

""T" Fitting 1/4 Compression Brass W/Nuts"

HYDRAULIC PREMIER SST, BXT, XPT COMPONENTS

DESCRIPTION	PB-REF
HARDWARE KIT SST DUAL, DUAL ACTING	H1170DDA
DUAL ACTING HPU 24V	DAHPU2
PORT OILDYNE PUMP 24V	PRIODHPUP
RELAY MODULE PORT 24V DA OIL	RMOILP24DA
Relay Module Stbd 24V DA Oil	RMOILS24DAD
RELAY MODULE PORT 12V SINGLE ACT	RMPORT12
RELAY MODULE PORT 12V DUAL ACT	RMPORT12DA
RELAY MODULE PORT 24 VOLT	RMPORT24
RELAY MODULE PORT 24V DUAL ACT	RMPORT24DA
RELAY MODULE, SINGLE ACTING, STBD, 12V	RMSTBD12
RELAY MODULE STBD 12V DUAL ACT	RMSTBD12DA
RELAY MODULE STBD 24 VOLT	RMSTBD24
RELAY MODULE STBD 24V DUAL ACT	RMSTBD24DA
BXA W/COIL, 10FT GREY EIC, W/LWR HINGE 316	BXADA10E-316
SSA W COIL, 10FT GREY EIC, W/LOWER HINGE 316 (PACKED)	SSADAC10E-316

ELECTRONIC INDICATOR CONTROL

DESCRIPTION	PB-REF
Integrated Helm Control (Hydraulic) Kit	OBI9000H
Electronic Indicator Control 12V (Packed)	EIC5000
Kit Electronic Indicator Control 24V (Packed)	EIC50002
Electronic Ind Ctrl 24V Less	EIC50002INT
Eic 24V, Spc Rm, Less Cable & Uh	EIC50002INTDA
Electronic Indicator Brdg Control 12V	EIC5000A
Electronic Ind. Brdg Ctrl 24V	EIC5000A2
Electronic Ind Brdg Ctrl Less	EIC5000AINT
Electronic Indicator Control Less Wires	EIC5000INT
Eic Control/Display	EIC001
Eic Gen 3 Display	EIC001G3
Eic Relay Module 12V	EIC101
Eic Relay Module 12V Dual Act	EIC101DA
Eic Relay Mod 12V Da Deutsch	EIC101DAD
Eic Relay, Da, 12V, W/Deutsch Hpu And Sensors	EIC101DADSD
Eic Rm G3	EIC101G3
Eic Relay Module 24V	EIC102
Eic Relay Module 24V Dual Act	EIC102DA
Eic Relay Mod 24V Da Deutsch W/Sensors	EIC102DADSD
Eic Bridge Junction Box	EIC701
Port Sensor W/10' Sc & Eic Connector	EIC901P
Wire Harness Eic 20Ft	EIC201
Wire Harness Eic 25 Ft	EIC20125
Wire Harness Eic 30 Ft	EIC20130
Wire Harness Eic 35 Ft	EIC20135
Eic Wire Harness Jnc Grey 4 Ft	EIC301
Eic Wire Harness Jnc Grey 6 Ft	EIC3016
Eic Pwr Cable Assy 14Awg 20A Fuse (Packed)	EIC401
Eic Bridge Wire Harness 20F	EIC801
Eic Bridge Wire Harness 25F	EIC80125
Hardware Kit Eic	EIC501
Hardware Kit Eic Bridge	EIC601
Eic Dual Pump Cable 10-10-01	EICWH10101
Eic Pigtail - Port	PT950P
Eic Pigtail - Starboard	PT950S

V.A.T. extra on U.K. sales, except Channel Isles. Packing & Carriage is extra, optimum time route & cost tailored to the clients needs. Quantity terms available on request.
